High-power CO2 laser marking machine
High-power CO2 laser marking machine
Specifications:

Device model: FL-RF60, FL-RF100, FL-RF150

Laser power: 60W, 100W, 150W

Laser wavelength: 10.64um

Beam quality (M2): ≤1.2

Laser repetition frequency: 20 ~ 200KHz

Marking range: 170 × 170 (mm), 300 × 300 (mm)

Maximum linear speed: 9000mm / s

Minimum line width: 0.1mm

Minimum character: 0.4

Cooling method: water cooling

Total power consumption: 3000W, 5000W, 6000W

Power demand: 220V / 50Hz

Appearance size: 880 × 1900 × 1700mm

Feature description

1. Adopt RF excitation sealed off CO2 laser, stable performance, can work for a long time;

2. Using high-speed digital scanning head, small size, fast speed and good stability;

3. The laser power is controlled by software, continuously adjustable, and marking and cutting can be realized on one product at the same time;

4. The marking is clear, not easy to wear, high engraving and cutting efficiency, environmental protection and energy saving;

5. No consumables and low processing cost.

Application area

It is mainly used for marking and cutting of non-metallic materials such as wood, bamboo, leather, rubber, cloth, paper, ceramics, stone, and acrylic. Such as: marking and cutting of graphics and text in product packaging, building ceramics, clothing accessories, footwear, handbags, buttons, glasses, fabric cutting, craft gifts, rubber products, electronic components, shell nameplates, stone processing and other fields.

Sample show
